Cutting Area : 4200 mm
FEEDRE SPEED Forwards : 25 m/min
FEEDRE SPEED Backwards : 60 m/min
RATE OF SAW FEED Forwards : up to 60 m/min
RATE OF SAW FEED Backwards : 60 m/min
Clamp Opening : 80 mm
SAW BLADES USED Diameter : min 250 mm – max 350 mm
SAW BLADES USED Inner Bore Diameter : 30 mm
SAW BLADES USED Projection Max Cut : 85 mm
SCORE BLADE Diameter : 200 mm
SCORE BLADE Inner Bore Diameter : 20 mm
Number Of Air Tables : 3
Number Of Clamps : 7
Dimensions : 8000x6800x1800 mm
