Description
Dimensions : 6900x5800x1700 mm
Number Of Air Table : 3
Number Of Clamps : 7
Cutting Area : 3803
Pushed Beam : 3850
Blade Protrusion : 65 mm
Grippers Opening : 55 mm
Minimum Alignement Width : 50 mm
Main Blade Diameter : 34
Main Blade Diameter Ext. : 320 mm
Main Blade Diameter Int. : 75 mm
Main Blade Teeth Width : 4.5 mm
Main Blade Body Thickness : 3.2 mm
Main Blade No. Of Teeth : 60
Main Blade Motor : 7.5 KW
Main Blade Rpm 50 Hz : 4865
Main Blade Rotation : 3440
Scoring Blade Diameter : 17
Scoring Blade Diameter Ext. : 200 mm
Scoring Blade Diameter Int. : 50 mm
Scoring Blade Teeth Width : 4.6 mm
Scoring Blade Body Thickness : 3.6 mm
Scoring Blade No. Of Teeth : 44
Scoring Blade Motor : 1.1 KW
Scoring Blade Rotation : 3440
Saw Blade Carriage Feeding Speed : 4 – 40 m/min
Return Carriage Feeding Speed : 45 m/min
Pusher Fast Speed : 0.8 – 13 m/min
Pusher Return : 15 m/min
