Description
Flue Diameter : 160 mm
Hot Air Delivery Pipes mm : 2×180 ø
Plenum Chamber : 160 mm
Flue Length : 500 mm
Oven Width : 400 mm
Oven Height : 590 mm
Fuels – Wood – Chips – Peat – P.C 3.500 KCal/KG
Flue Capacity : 29.900 KCal/h
Conventional Yeld Capacity : 25.000 KCal/h
Air Flow (at 15⁰) : 2.200 mc/h
Flue Consumption P.C. 3.500 : 13 KG/h
Fan Electric Power : 0.2 HP
Electric Power Od Flue-Gas Exhaust
Motor Voltage : 220 V
Dimensions : 750x560x1550 mm
