Description
Dimensions : 6000x1200x1700 mm
Edgeband Height Max : 60 mm
Thickness Of Coiled Edgeband Max : 3 mm
Feedrate Max : 18-20 m/min
Workpiece Length Min : 180 mm
Workpiece Width Min : 60 mm
Motorized height adjustment
Motorized intake fence
Pre-milling unit
Glue system cartridge+ granulate
Suitable for PUR glue
Motorized pressure unit
Pneumatic end trimming unit
Cutting unit with NC servo axes (6 motors)
Corner roundind unit with NC servo axes (2 motors)
Motorized scraper unit
Glue scraper
Spraying device
Buffing unit
