Description
Max. Squaring Stroke (E.C/non E.C.) : 2660 mm
Cutting Width On Rip Fence : 1270 mm
Table Dimensions : 940×560 mm
Max. Diameter Of Saw Blade With Scoring Unit Installed : 400 mm
Saw Blade Tilting : 90 – 45°
Max. Saw Blade Projection At 90° From Table With Blade: 400 mm 138 mm
Max. Saw Blade Projection At 45° From Table With Blade: 400 mm 98 mm
Saw Blade Rotation Speed : 3800 RPM
Scoring Blade Rotation Speed : 9200 RPM
Exhaust Outlet Diameter : 120 mm
Blade Protection With Exhaust Outlet Diameter : 60 mm
Weight : 700 KG
Dimensions : 3300x900x1250 mm
Ribbed cast-iron worktables
Saw blades lifting and tilting by handwheels
Independently powered scoring unit with blade ? 120 mm, Z=20
Anodized aluminium alloy carriage (dimensions 330x146x2600mm) The high precision hardened steel guides are fixed on the carriage by means of mechanical bending system which allows fast and precise movements
Readout of saw blades tilt on the machine front side
Squaring frame complete with swinging arm support and telescopic fence with crosscut flip-over stops with direct reading of cutting dimensions
Rip fence with micrometric adjustment and locking system by eccentric pin
Cylindrical sliding bar for rip fence with rectified steel round bar 45 mm
Eccentric clamping
Table with extension on outfeed side
Overload switch protection
Emergency pushbutton
Padlockable main switch
Direct start main motor
Circular saw with tilting blade with overload protection
Saw blade protection on riving knife
